PMP135 Absolute and gauge pressure transmitter

Product Item : PMP135-A1G01A1N
Category： Pressure
Measuring Principle:Absolute and gauge pressure
Characteristic:Cost-effective pressure transducer with piezoresistive sensor, and flush mounted metallic diaphragm for hygienic applications
Supply voltage:Analogue output: 12...30V DC, Switch output: 18...32V DC
Process connection:Threads Tri-Clamp ISO2852 Hygienic connections
INQUIRY EMAIL

Absolute and gauge pressure Cerabar PMP135

Cost-effective pressure transducer with fully welded metal sensor for use in hygienic applications

The Cerabar PMP135 is a price-attractive compact pressure transmitter with metal sensor and flush-mounted metallic diaphragm for hygienic applications for absolute and gauge pressure measurement.

Benefits

Compact pressure transducer for hygienic applications
Suitable for CIP / SIP cleaning
Small flush mounted hygienic process connections with 3-A and EHEDG certification

Field of application

Pressure transducer for measuring absolute pressure and gauge pressure in gases, vapors, liquids and dusts.

Process connections: Hygienic connections
Process temperature: -25 to +100°C (-13 to +212°F), +135°C (275°F) for max. 1 h
Pressure: -1/0 up to +40bar (-15/0 to +600psi)
Accuracy: ±0.5%
International explosion protection certificates, hygienic certificates

Features and specifications

Pressure

Measuring Principle	Absolute and gauge pressure
Characteristic	Cost-effective pressure transducer with piezoresistive sensor, and flush mounted metallic diaphragm for hygienic applications
Supply voltage	Analogue output: 12...30V DC, Switch output: 18...32V DC
Reference Accuracy	0,5%
Long term stability	0,15% of URL/year
Process temperature	-25°C...100°C (-13°F...212°F) 135°C for 1h (275°F for 1h)
Ambient temperature	-25°C...70°C (-13°F...758°F)
Measuring cell	1bar...40bar (15psi...600psi)
Max. overpressure limit	160bar (2320psi)
Process connection	Threads Tri-Clamp ISO2852 Hygienic connections
Communication	4...20mA analogue PNP switch
Certificates / Approvals	ATEX
Safety approvals	SIL
Design approvals	EN10204-3.1
Hygienic approvals	3A
Specialities	switch output
